| standard configuration | 8 10/100M RJ-45 MDI/MDI-X ports, |
| Transmission medium |
10/100BASE-TX: cat3、4、5 UTP（≤100m） |
| Dimension | 190mm x120mm x35mm |
| MAC address table | 1K |
| Buffer | 56 Kbit |
| backboard bandwidth | 1.6Gbps |
| LED light | power 、POE、Link/Act |
| power input | 48V DC/1.25A |
| Consumption | 59W |
| POE | Provide 1-4 port POE power supply, each port maximum power 15.4W,full load 52W. |
|
environment temperature |
0-40℃ operation， -10-70℃ preserve， |
|
environment humidity |
Operate:10-85% non-condensing, Storage:10-90% non-condensing, |
